Aston Martin Vantage / DB9 / DBS Honeycomb Side Vents

Bring the honeycomb treatment down the side of your Aston Martin with complete replacement side vents. They replace the original side vent/mesh assembly, refreshing ageing mesh and giving the side grilles a design that works with matching bonnet vents.

The AstonDIY honeycomb range

Josh wanted a more consistent exterior design on his own Vantage. The honeycomb detail around its N420 rear diffuser provided the inspiration for this independently developed AstonDIY vent range.

• A matching left and right side vent pair, replacing the relevant assembly rather than covering it with an overlay.
• Open honeycomb geometry keeps ventilation through the side vent opening.
• Engineering-polymer construction provides UV resistance, weather resistance and durability for outdoor use.

Compatibility & contents

Suitable for VH Aston Martin Vantage, DB9 and DBS side vent applications. One left side vent and one right side vent are supplied. The vehicle’s original bolts are reused; no replacement hardware is included.

raw black finish

Fit the vents in the supplied raw black finish, or prepare and paint them if desired. Customers have successfully painted these components to suit their cars. Painting is not included.

Installation

Each side vent uses three original bolts. Access is from inside the wheel arch, so the wheel-arch liner must be removed or moved sufficiently to reach the fixing points.

Allow around 30 minutes for installation; access and vehicle condition may affect the time needed.

Match the bonnet vents

Choose matching Vantage honeycomb bonnet vents or DB9 honeycomb bonnet vents, checking the separate bonnet fitment requirements. Browse more VH Vantage or DB9 and DBS parts.

The vent design has run on Josh’s own Vantage for over three years, and more than 50 sets have been supplied across the honeycomb range.

Dispatch & support

Orders normally dispatch within 3–4 working days, with two dispatch runs each week. For fitment help, contact AstonDIY. Please read our additive manufacturing policy and shipping, taxes and returns information.
